Direct-drive servo motor
The motor is integrated into the machine head. Set a suitable maximum speed using the front controls, then vary your sewing pace with the foot pedal.
ZOJE B9500-70 · 5 × 5mm safety stitch
A joined seam.
A neatly finished edge.
Bring garment assembly and edge finishing together with the ZOJE B9500-70 direct-drive five-thread overlocker. Its wide safety stitch combines a joining chainstitch with an overlocked edge, completing both operations in one pass.
The 5 × 5mm configuration gives you a 10mm overall seam width, with adjustable speed, needle positioning and LED lighting to support everyday sewing.
2 needles · 5 threads5 × 5mm setupComplete table & stand
Understand the 5 × 5mm setup
Five threads, working together.
The two needles and five threads form a safety seam: a separate chainstitch joins the fabric, while the overedge stitch finishes the trimmed edge. Here, 5mm needle spacing plus 5mm overedge width gives a 10mm overall seam.
This wide-seam configuration is useful for garment construction where the pattern and seam allowance call for a five-thread safety stitch. Match your fabric, thread and needle selection to the job, and test the assembled seam before production.
Needle positioning
A built-in needle positioner provides a consistent stopping position as you guide successive sections of the seam.
Differential fabric feed
Adjust the feeding action to suit the material and help manage stretching or gathering as the fabric passes through the machine.
LED sewing-area light
See the needle area and fabric edge more clearly while threading, aligning your work and checking stitch formation.
Complete industrial setup
Built up and ready for your workroom.
The B9500-70 is supplied complete on a 1.2m × 0.55m table and stand, with limited height adjustment.
Table and stand colours may vary from those pictured.
Included with your machine
- ZOJE B9500-70 direct-drive five-thread overlocker
- Table and stand, supplied built up
- Needles and tweezers
- Needle screwdrivers
- Sewing machine oil
At a glance
Your B9500-70 configuration.
- Model
- ZOJE B9500-70
- Needles and threads
- 2 needles / 5 threads
- Seam type
- Five-thread safety stitch: chainstitch plus overedge finish
- Needle gauge
- 5mm
- Overedge width
- 5mm
- Overall seam width
- 10mm — 5 + 5mm configuration
- Drive and control
- Direct-drive servo, adjustable speed and needle positioning
- Fabric feed
- Differential bottom feed
- Needle system
- DC×27 / B27
- Table dimensions
- 1.2m long × 0.55m deep
Choose by seam construction, not just thread count.
The B9500-70 is the 5 × 5mm wide-seam configuration. For bulky fabrics, coated materials or upholstery, ask us to check your full seam assembly before selecting a machine. A five-thread safety-stitch overlocker is different from a coverstitch machine used for parallel-stitched stretch hems.
Find the right fit for your sewing.
Tell us about your fabric, seam allowance and the thickness at your busiest seam intersections. We can help you decide whether the B9500-70 is suitable and choose matching needles and thread.
